Unloader DM 1.8 Injector

Brand:
Mfr. Model #:
YVB135KDMI18
KR Part #:
GP135KDMI18
Weight:
1.80 lbs
Call For Availability
MSRP
$228.33
Now Only!
$86.39
starstarstarstarstar (0)

A direct mount unloader designed to connect with TT and TP 51 Series pumps. It comes equipped with a chemical injector with a 1.8mm orifice. Handles a maximum pressure of 2600 PSI and flow rate of 6.5 GPM.




Technical Specifications

Max GPM: 6.5
Max PSI: 2600
Inlet Port: 3/8 inch
Outlet Port: 3/8 inch
Max Temperature: 195 degrees F

Product Description

6.5 GPM - Direct Mount Unloader w/ Chemical Injector
The General Pump YVB135KDMI18 is an unloader that is engineered for compatibility with TT and TP Series 51 pumps. It features an integrated unloader that has a 1.8 mm orifice. This direct mount unloader is able to withstand a maximum pressure of 2600 PSI and a flow rate of 6.5 GPM. Rated for a continous pressure of 2300 PSI. Inlet and outlet measure 3/8 inch in diameter and are equipped with BSP threading. Threading on the inlet is female and the outlet threading is male.

Specifications:

  • Product Number: YVB135KDMI18
  • GPM: 6.5
  • Rated PSI: 2300
  • Max PSI: 2600
  • Inlet: 3/8" BSP-F
  • Outlet: 3/8" BSP-M
  • Injector: 1.8 mm
  • Temperature: 195° F
  • Compatible Pumps: TT/TP Series 51 Pumps
