150 GPM - Industrial Pneumatic Diaphragm Pump

The Husky 2150 is an industrial grade air-operated diaphragm pump with a PTFE/EPDM diaphragm that is great for handling applications involving antifreeze, detergents, motor oil, hydraulic fluid, water, and wastewater transfer. The air valve is engineered to deliver stall-free, low pulsation operation for smooth and rapid changeover. Air valve maintenance is easy, as it is accessible from the outside of the pump. This means you won't need to remove the pump from the air or fluid line.

Features:

• Overall improved efficiency (up to 40% more efficient)
• Highest fluid flow rate in its class
• Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps
• Expanded material offering to handle endless applications
• Fewer parts than industry peers, the air valve is externally accessible so it can be serviced quickly and easily without uninstalling the diaphragm pump
• 2 in. (51 mm) ANSI end-porting
• Fluid flow up to 150 gpm (568 lpm)
• Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)
• Lube-free operation
• Epoxy-coated air section for tough environmental conditions

Husky 2150 Specifications:

• Air Exhaust Port Size (in): 3/4
• Air Exhaust Port Thread Gender: Female
• Air Exhaust Port Thread Type: NPT
• Air Inlet Size (in): 1/2
• Air Inlet Thread Gender: Female
• Air Inlet Thread Type: NPT
• Application: Industrial
• Ball Material: PTFE
• Center Section Material: Aluminum
• Compatible Material: Antifreeze, Detergents, Motor Oil,
• Hydraulic Fluid, Water - Wastewater Transfer
• Connection Type: Threaded
• Diaphragm Compatible Material: PTFE
• Diaphragm Material: PTFE/EPDM 2-Piece
• Fluid Inlet Size (in): 2
• Fluid Inlet Thread Gender: Female
• Fluid Inlet Thread Type: NPT
• Fluid Outlet Size (in): 2
• Fluid Outlet Thread Gender: Female
• Fluid Outlet Thread Type: NPT
• Fluid Section Material: Aluminum
• Manifold Configuration: End Port
• Manifold O-Ring Material: PTFE
• Material: Aluminum
• Maximum Air Consumption (SCFM): 175
• Maximum Air Pressure (MPa): 0.8
• Maximum Air Pressure (psi): 120
• Maximum Cycle Rate (CPM): 145
• Maximum Flow Rate (GPM): 150
• Maximum Fluid Pressure (MPa): 0.8
• Maximum Fluid Pressure (psi): 120
• Maximum Operating Temperature (°F): 180
• Maximum Solid Size (in): 0.25
• Model: Husky
• Overall Height (in): 23.6
• Power Source: Air
• Seat Material: Stainless Steel
• Series: 2150
• Part Number: DF3311
• Standards Met: ATEX, CE
• Type: Pneumatic Diaphragm Pump
• Wetted Material: Aluminum, Stainless Steel, PTFE/EPDM
