Baldor 7.5 HP Electric Motor

The Baldor EM3311T is a 7.5 hp electric motor for high-power performance at your facility. Heavy duty frame and copper windings for applications needing continuous or frequent duty. Great for pumps, compressors, fans, conveyors, machine tools, and other general-purpose three-phase applications. Uses an open drip proof design.

Features

• Pressure cast aluminum end plates with ribbed design for rigidity
• Locked drive end bearing
• Heavy gauge steel frame
• Optimized airflow design provides higher horsepower in smaller package
• Open drip proof motor or OPSB
• 91.0% efficiency at 100% load

Specifications

• RPM: 1770
• Horsepower: 7.5
• Phase: Three
• Voltage AC: 230/460
• Max Ambient Temperature: 104°F

Applications

Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

UPC:

• 781568104675
