General Pump ETB1811S17L Electric ETB Series Triplex Plunger Pump - 3.70 GPM, 2320 PSI, 1750 RPM, Left Shaft

Brand:
Mfr. Model #:
ETB1811S17L
KR Part #:
GPETB1811S17L
Weight:
11.00 lbs
Out of Stock - Pre-Order Now
MSRP
$880.79
Now Only!
$300.77
starstarstarstarstar (0)
A triplex plunger pump with a forged brass manifold and ceramic plungers to deliver a longer life span. The solid, left-side mounted driveshaft measures 24mm. Delivers a maximum flow rate of 3.70 GPM.

Note: Picture shows right pump shaft - this pump comes with a LEFT MOUNTED pump shaft.



Product Description

24 mm Solid Shaft Plunger Pump

The General Pump ETB1811S17L is an electric triplex plunger pump from the ETB series. It is built with a forged brass manifold to increase the durability of the pump's head. Plungers are made with solid ceramic to improved strength. Designed with a 24mm solid shaft, mounted on the left side. The pump is engineered to endure a maximum pressure of 2320 PSI, handles a maximum speed of 1750 RPM, and produces a flow rate of 3.70 GPM.

Specifications:
  • GPM: 3.70
  • PSI: 2320
  • RPM: 1750
  • HP: 5.98 EBHP
  • Maximum Inlet Pressure: 125 PSI
  • Max. Inlet Vacuum: 3 ft. water (2.6 Hg) Flooded
  • Plunger Bore: 0.708 in./18 mm
  • Plunger Stroke: 0.433 in./11 mm
  • Oil Capacity: 8.5 oz.
  • Maximum Fluid Temperature: 165° F
  • Inlet Port Thread: 1/2"-14 BSP-F
  • Discharge Port Thread: 3/8"-19 BSP-F
  • Shaft Diameter: 0.945"/24mm, Left Side
  • Weight: 11.0 lbs.
  • Dimensions: 8.0" x 7.4" x 4.7"
Features:
  • Durable forged brass manifold
  • Dust protection chamber
  • Solid ceramic plungers
  • Advanced plunger mounting system
  • Valve cover for ease of service
  • 24mm solid shaft, left side mounted
