General Pump ETB1811S17 Electric ETB Series Triplex Plunger Pump - 3.70 GPM, 2320 PSI, 1750 RPM

Brand:
Mfr. Model #:
ETB1811S17
KR Part #:
GPETB1811S17
Weight:
11.00 lbs
Out of Stock - Pre-Order Now
MSRP
$880.79
Now Only!
$300.77
starstarstarstarstar (0)
A triplex plunger pump with a forged brass manifold and ceramic plungers to deliver a longer life span. The solid, right-side mounted driveshaft measures 24mm. Delivers a maximum flow rate of 3.70 GPM.



Product Description

24 mm Solid Shaft Plunger Pump

The General Pump ETB1811S17 is an electric triplex plunger pump from the ETB series. It is built with a forged brass manifold to increase the durability of the pump's head. Plungers are made with solid ceramic to improved strength. Designed with a 24mm solid shaft, mounted on the right side. The pump is engineered to endure a maximum pressure of 2320 PSI, handles a maximum speed of 1750 RPM, and produces a flow rate of 3.70 GPM.

Specifications:
  • GPM: 3.70
  • PSI: 2320
  • RPM: 1750
  • HP: 5.98 EBHP
  • Maximum Inlet Pressure: 125 PSI
  • Max. Inlet Vacuum: 3 ft. water (2.6 Hg) Flooded
  • Plunger Bore: 0.708 in./18 mm
  • Plunger Stroke: 0.433 in./11 mm
  • Oil Capacity: 8.5 oz.
  • Maximum Fluid Temperature: 165° F
  • Inlet Port Thread: 1/2"-14 BSP-F
  • Discharge Port Thread: 3/8"-19 BSP-F
  • Shaft Diameter: 0.945"/24mm, Right Side
  • Weight: 11.0 lbs.
  • Dimensions: 8.0" x 7.4" x 4.7"
Features:
  • Durable forged brass manifold
  • Dust protection chamber
  • Solid ceramic plungers
  • Advanced plunger mounting system
  • Valve cover for ease of service
  • 24mm solid shaft, right side mounted
